DC Axial Fan
70x70x15mm DC Axial Fan
Technical Parameters of the DC Axial Fan
| Dimension (mm) |
Model |
Voltage (VDC) |
Current (AMP) |
Power (Watts) |
Speed (RPM) |
Air Flow (CFM) |
Pressure (Inch/H2O) |
Noise (dBA) |
Weight (Gram) |
| 70X70X15 |
PD70S-12L |
12 |
0.18 |
2.16 |
4000 |
27.6 |
3.76 |
35.20 |
48 |
| PD70S-12M |
12 |
0.21 |
2.52 |
4500 |
29.5 |
4.16 |
37.03 |
48 |
| PD70S-12H |
12 |
0.25 |
3.00 |
5000 |
32.1 |
4.69 |
39.24 |
48 |
